TRX3118A SUBWOOFER:
The TRx3118A is an active compact subwoofer that extends the low frequency to 37 Hz providing exceptional impact for any sound system. The high excursion TS18C 18-inch cone and 4-inch (100mm) voice coil produces tremendous force from the direct radiating, ported bass reflex design. The high 131 SPL capacity and powerful bass projection make this an ideal subwoofer for portable live sound applications and installations. Simple setups are done through 4 presets for LIVE, PLAYBACK, SPEECH and SUB ONLY. Everything is managed by the Analog Devices™ DSP to maintain high headroom, distortion-free performances. The amplifiers deliver 2000W, 1000W for the 18-inch sub and 1000W for the HF SATELLITE output for the TRx3900 column arrays through a twist-lock connector. The tour-grade enclosure features multi-ply hardwood for the integrity of the cabinet while the DuraTec™, a polyurethane outer finish, provides UV and moisture protection. The TS18C woofer is protected by the heavy-duty powder coated perforated steel grill and protective cloth backing. Recessed handles are center balanced for easy deployment.

TRx3118A SPECIFICATIONS:
»System Type: 18-inch Subwoofer, Active Bass Reflex
»Frequency Response: 37Hz - 200Hz
»Power : 2000W Program (1000W subwoofer, 1000W HF)
»DSP Processing: Live,Playback,Speech,Sub Only
»Coverage Pattern: Omni
»Maximum SPL: 131dB
»LF: TS18C-4 18-Inch Woofer 4Ω,100mm (4-inch) Voice Coil
»HF Satellite Output: 4Ω
»Enclosure: Premium Multi-Ply Hardwood
»Finish: Black DuraTec™
»Grill: Black powder coated 16-ga steel with acoustic cloth
»Transport: 2 Recessed handles
»Pole Mount: Standard 1.38-inch pole mount cup
»Suspension points: None
»AC Input: 115V-230V (50-60Hz)
»Net Weight: 75lbs (34kg)
»Dimensions: 23.6”W x 23”D x 21.2”H

TRX3900 COLUMN ARRAY:

The TRx3900 Column Array is a high output, easy to carry sound reinforcement loudspeaker providing enhanced coverage with superb fidelity. Exclusively equipped with 9 Carvin Audio 3.5-inch transducers, it’s designed for all genres of music and venues, ranging from small to large events. The Constant Delivery Dispersion “CDD™” projects to the rear of the venue while averaging levels up front and its wide 120º dispersion covers larger audiences. The 10º vertical dispersion substantially minimizes feedback in reverberant environments. The TRx3900 power is supplied by the TRx3118A subwoofer delivering 1000W, 500W into each TRx3900, or by your own amplifier system. The tour-grade enclosure features multi-ply hardwood for the integrity of the cabinet while the DuraTec™ finish, a polyurethane outer skin, provides UV and moisture protection. Projecting far into your audience, the TRx3900 delivers the most pleasant, unfatigued listening experience, and offers high intelligibility from a compact column.

TRx 3900 SPECIFICATIONS:
»System Design: Column Array, Passive
»CDD™Constant Delivery Dispersion
»Frequency Response: 110Hz – 18kHz
»Crossover Required: 110Hz 24dB/Oct HI PASS
»Maximum SPL: 126dB continuous, 129dB peak
»Power Handling: 200W continuous, 800W peak
»Impedance: 8Ω
»Connectors: 2 Two Conductor Twist Lock, IN-THRU

TRANSDUCERS:
»Model:PS3.5-8
»Transducers: 9 x 3.5-Inch

ENCLOSURE:
»Horizontal/Vertical Dispersion: 120°/10°
»Construction Material: Multi-Ply Hardwood
»Finish: DuraTec™ polyurethane
»Grill: Black powder coated steel with acoustic cloth backing
»Enclosure Protection: Moisture/UV
»Transport: 1 recessed handle
»Standard Pole Mount: 1 3/8-in cup
»Dimensions (W x D x H): 5”W x 5.5”D x 35”H
»Weight: 23 lbs.

“We purchased four of the TRx column array speakers to use with our TRx2118 subs... We were all amazed with the tone, clarity, definition, coverage & volume produced from these compact enclosures. Everything about these cabs is stellar. The vocals & instruments are clean & detailed. Coverage & dispersion from front to back, left to right of the venue is even & clear - virtually eliminated hot spots & dead spots.They have far exceeded our expectations and have made a huge improvement in the sound quality of our band.” – John Hudson Boston, MA
