1- QX5A Active Monitor with 3 Channel Mixer
1 -Top Mount Mic Extension Pole with 3/8-16 and 5/8 adapters
1 -Microphone Stand Mount with 3/8-16 threaded adaptor
The QX5A is designed to function as both a powered near field monitor and as a three channel mixer/monitor with an external output to send to a QX15A or SCx Series powered main speaker for live performances. The QX5A is ideal for the solo performer who wants an all in one mixer/monitor with the ability to connect a larger active main speaker or amplifier for live performances in small to medium size venues. Houses of Worship can benefit from the compact near field design, allowing audio from the mixing console to be sent directly to the performer(s) on stage and allowing the performer to adjust his or her own volume and tone as needed.
»System Type: 5-inch, Active Near Field Monitor
»Speaker Cabinet Frequency Response: 80Hz-14kHz
(-10dB) 100Hz-10kHz (-3dB)
»Three Channel Mixer
»SYSTEM EQ: 3-Band with cut/boost +/- 15dB
LOW 100Hz, MID 2.5kHz, HIGH 12kHz.
»MIC/LINE IN to THRU Frequency Response: 20Hz-
»Power: 150W Program
»Input Impedance: 20k 0hms
»Sensitivity (1w/1m): 98dB
»Maximum SPL: 114dB
»Maximum Input Signal: +20dBu
»Speaker: 5-Inch Woofer 6 Ohms
»Enclosure: Virgin polypropylene
»Grill: Black powder coated 18-ga steel
»Transport: 1 Top Handle
»Pole Mount: 16mm (0.63-inch) pole mount cup
»Pole Mount Adapter: 3/8-16
»Top Mount: 3/8-16
»Top Mount Mic Extension Pole: 3/8-16 and
5/8 adapters. Extension Pole length is 6.75-inches
»AC Input: 100V-230V (50-60Hz)
»Fuse: T3.15A-250V 20mm x 5mm
»Net Weight: 6.1lbs (2.8kg)
»Dimensions: 11.25”W x 7.0”D x 8.0”H
The QX15A is our finest 15-inch active loudspeaker ever produced over its 20 years of history of previous models. Loaded with premium features including DSP processing from Analog Devices™ delivers controlled sound from its 4 selections of normal intelligent sound, monitor playback, DJ and external sub functions.
Featured are 2 amplifiers, one for the bass and the other for high frequencies that enhances intelligibility, plus power to spare from its continuous 1000 watts output. Its deep, rich bass and crystal-clear high-end projects far to the rear with intelligent articulation so everyone can hear clearly.
Three different inputs are offered for Mic, Line or BT operations with an extended rangeBluetooth™ streaming stereo wirelessly from your phone or tablet. Pair a second QX15A for a true wireless stereo setup or mono operation that doesn’t require a 2ndcable to connect.
The universal power supply adapts to all countries for 115 or 230 VAC 50-60 Hz operation. The QX15A can be used with a stand, as a floor monitor or installed from its 3-point mounting system. Its precision assembly and rugged design is ideal for touring, which is water resistant from a molded enclosure and powder coated steel grill.
The QX15A a is premium, universal powered loudspeakers that projects distortion-free, high fidelity audio to its audience.
System Type: 15-inch 2-way, Active Bass Reflex
» Frequency Response: 54Hz-18kHz (-10dB) 62Hz-16kHz (-3dB)
» Power: 1000W Program
» Coverage Pattern: Main 90x60 Monitor 60x90
» Sensitivity (1w/1m): 98dB
» Maximum SPL: 130dB
» Maximum Input Signal: +12dBu
» LF: 15-Inch Woofer 4 Ohms
» HF: 1.74-Inch 8 Ohms
» Enclosure: Virgin polypropylene
» Color: Black
» Grill: Black powder coated 16-ga steel with cloth backing
» Transport: 2 Recessed handles
» Pole Mount: 1.38-inch pole mount cup with thumb screw
» Suspension Points: 3 points using M8-1.25 x 30mm. The bottom fly points are 180mm center to center.
» AC Mains Input: 115V-230V (50-60Hz)
» Net Weight: 42lbs
» Dimensions: 17.75”W x 15.5”D x 27.5”H
"I love this Carvin QXSYS15A sound system. Sounds great! I’m sold on the sound and quality. My goal by Christmas is to add the TRC400A." David C. Augusta, GA
Premium 25' Speaker cable with twist lock connectors. Specifications: Connector : NL4 Twist LockLength : 25' FeetConductor Type : CopperWire Gauge : 12 ga.Speaker Cable: YesIntended for : Connecting passive speakers with twist lock connections to a power ampWarranty: 1 YearView full product details
